LDN4 Square Series

LDN4 Square – 4” Open and Wallwash

By Lithonia Lighting

    Switchable Lumens  Switchable CCTs  Energy Star®  Buy America(n)
  • Overview
  • Specifications
LDN 4”downlights are the most cost-effective solutions for commercial-grade downlight applications seeking general illumination. The square construction has a durable, metal trim providing a crisp geometric look in both open and wallwash configurations.
Key Features
  • LDN Switchable (SWW) is now available with (4) Switchable CCTs options, (4) lumens packages, and multiple dimming options
  • 55° cutoff and 75+ LPW
  • 1.0 Spacing/Mounting Height ratio
  • Open wallwash kicker available
  • eldoLED drivers (10% or 1% min dimming)
  • Available with nLight® AIR capability for wireless control and connectivity
  • Configurations support A+ Certified Solutions

LDN4SQ is now available with SensorSwitch JOT!
  • Wireless, app-free solution to single room lighting control
  • Absolutely no 0-10V control wires and no mobile apps are needed to install and pair JOT enabled products
  • Lightning speed installation right out of the box all and pair JOT enabled products
Read More
Read Less
Size 4 IN
Shape Square
Light Source LED - Static
Dynamic Feature Switchable White
Lumens 500 LM, 750 LM, 1000 LM, 1500 LM, 2000 LM, 2500 LM, 3000 LM, 4000 LM, Switchable
CCT / LED Color 2700 K, 3000 K, 3500 K, 4000 K, 5000 K
CRI 90
Product Type Downlight
Compliance Listing BAA, Chicago Plenum, ENERGY STAR®
Environmental Listing ASTM Airtight
Regulatory Listing cUL
Dimming Protocol 0-10V, DALI, Electronic Low Voltage, Triac
Fixture Wattage 10.6, 13.4, 13.5, 14.9, 16.4, 17.5, 22.1, 25, 25.6, 26.1, 27.1, 28.6, 32.1, 37.5, 37.6, 39.1, 40.6, 43, 5.7
Voltage Rating 120, 120-277, 277, 347
Trim Style Single Wallwash
Color Black, Clear, White
Mounting Type Recessed
Series LDN4SQ

Read More Read Less
