D-Series Surface Canopy

D-Series Parking Garage LED Outdoor Surface Canopy

by Lithonia Lighting

The energy savings, long life, and easy-to-install design of the D-Series LED Surface Canopy luminaire make it the smart choice for canopy lighting in commercial, industrial and institutional applications with mounting heights of 8-15’.


Construction

Two-piece die-cast aluminum housing has integral heat sink fins to optimize thermal management through conductive and convective cooling. Modular design allows for ease of maintenance and future light engine upgrades. The LED drivers are mounted in direct contact with the casting to promote low operating temperature and long life. Housing is completely sealed against moisture and environmental contaminants (IP66) and is suitable for hose-down.

Finish

Exterior parts are protected by a zinc-infused Super Durable TGIC thermoset powder coat finish that provides superior resistance to corrosion and weathering. A tightly controlled multi-stage process ensures a minimum 3 mils thickness for a finish that can withstand extreme climate changes without cracking or peeling.

Optics

Precision-molded proprietary acrylic lenses provide five different photometric distributions suited to a variety of canopy and walkway applications. Light engines are available in 3000K (80 min. CRI), 4000K (70 min. CRI) or 5000K (65 min. CRI) configurations.

Electrical

Light engines consist of 10 high-efficacy LEDs mounted to a metal-core circuit board to maximize heat dissipation and promote long life. The electronic driver has a power factor of >90%, THD <20%, and a minimum 2.5 KV surge rating. When ordering the SPD option, a separate surge protection device is installed within the luminaire which meets a minimum Category C low operation (per ANSI/IEEE C62.41.2).

Installation

Mounts to a 4x4” recessed or surface mount outlet box using a quick-mount kit (included); kit contains galvanized steel luminaire and outlet box plates and a full pad gasket. Kit has an integral mounting support that allows the luminaire to hinge down for easy electrical connections. Luminaire and plates are secured with captive screws.

Other

Warranty

Five year limited warranty. Full warranty terms located at www.acuitybrands.com/CustomerResources/Terms_and_conditions.aspx.

Note: Specifications subject to change without notice.

  • Suggested Replacement Products

  • Spec Sheets

    Document Type Document Title Description Updated View
    {{document.DocumentType}} {{document.DocumentTitle}} {{document.Description}} {{document.UpdatedDate | date: 'MM/dd/yy'}} View
  • Specifications

    Brand Lithonia Lighting
    Color Bronze, Silver, White
    Control Networkable Control, Occupancy Sensor
    CCT 3000 K, 4000 K, 5000 K
    Environment Outdoor
    Finish Gloss
    Light Source LED - Static
    Regulatory Listing CSA
    Lumen Output 2000 LM, 3000 LM, 4000 LM, 5000 LM, 6000 LM, 7000 LM, 8000 LM, 9000 LM, 10,000 LM, 11,000 LM, 12,000 LM
    Mounting Type Surface
    Product Type Canopy
    Series DSXSC
    Shape Rectangular
    Voltage Rating 120, 208, 240, 277, 347, 480, MVOLT
