Z Strip

Z Series Fluorescent Striplights Discontinued

The industry's next generation in linear direct fluorescent products. This new compact, low-profile design offers our customers unique product features which improve the overall installation process and appearance while reducing labor cost, making it the most versatile solution for commercial, retail, manufacturing, warehouse, and cove and display applications.

Designed to accommodate a wide variety of T5, T5HO and T8 lamp lengths. Channel offers the gripper back feature which strengthens the overall construction and allows for the use of the Z spring hanger (see back). Patent-pending fastener-less channel cover offers a secure fit design allowing for quick attachment and easy access without pinching wires.

Construction

Compact designed channel and cover are formed from code-gauge cold-rolled steel. Locking lamp holder tracks bolsters strength of the overall strip construction while creating improved lamp stability. Design includes T5 or T8 socket, features rotating collar and enclosed contacts. Improved easy “snap n’ lock” end plates allow for quick attachment. Patented-pending “three-point” row connector locks channel together for straighter and faster rows mounting; included as standard.

Finish: High-gloss, baked white enamel finish (white standard). Five-stage iron-phosphate pretreatment ensures superior paint adhesion and rust resistance. Standard channel paint finish options: black (MB), smoke gray (SKGY) and galvanized (GALV).

Optics

Reflector options include solid designs in both symmetric and asymmetric configurations. Consult factory for different-apertured versions.

Electrical

Thermally protected, resetting, Class P, HPF, non-PCB, UL listed.

Suitable for damp locations. AWN, TFN or THHN wire used throughout, rated for required temperatures.

Installation

Patented-pending “three-point” row connector locks channels together for straighter and faster rows mounting; included as standard. Ideal for surface-mount or suspended.

Read Less

Size	2FT, 3FT, 4FT
Shape	Rectangular
Light Source	Fluorescent
Lumens	Not Applicable
Product Type	Strip Light
Environmental Listing	Damp Location
Regulatory Listing	CSA, NOM
Fixture Wattage	14, 17, 25, 28, 32, 54
Voltage Rating	120, 120-277, 208, 240, 277, 347
Color	Black, Silver, White
Mounting Type	Surface, Suspended
Series	TZ, Z

Read More Read Less

Spec Sheets

Document Type	Document Title	Description	Updated	View	Download	Email
Spec Sheet	Z-T-T8 Spec Sheet (Discontinued)	Z strip low-profile T5 & T8, one or two lamps, symmetric, asymmetric or no reflector (Discontinued)	11/15/2021	View	Download	Email

Photometry & Revit (BIM)
Spectral Data Sheets

Technical Documents (e.g. Instruction Sheets, MSDS, CAD)

Document Type	Document Title	Description	Updated	View	Download	Email
Installation Instructions	Z Strip Installation Instructions	Z Strip Installation Instructions	1/21/2019	View	Download	Email
Installation Instructions	ZACVH Instruction & Drawing_101811.pdf	Adjustable 10' aircraft cable with Y hanger	4/28/2021	View	Download	Email
Installation Instructions	ZSPRG Instruction & Drawing.pdf	Tong and T-grid hanger, for 15/16" T-grid	4/28/2021	View	Download	Email

Utility Rebate Search
Replacement Parts
Confidential Documents

Marketing Material (e.g. Brochures, Sell Sheets, FAQs)

Document Type	Document Title	Description	Updated	View	Download	Email
Brochures	Z_Series_Combo_Flyer	Z Series Combo Flyer	11/7/2012	View	Download	Email
