L7XR

L7XR

6" Incandescent Remodel Housing

by Lithonia Lighting

Recessed incandescent housings for 2x8 remodel construction. Approved for direct burial in insulation and all ceiling and wiring types.


Construction

L7XR: Air-tight aluminum housing with heavy-gauge galvanized steel raceway arm. Remodel clips for installation in existing plaster, sheet rock or mechanical ceilings. Galvanized steel junction box with three built-in ROMEX® clamps and ground wire. Not suitable for pulling wires. Rated for 90°C. Socket clips to trim to ensure proper and consistent lamp position.

Trim retention (clips): Retaining clips riveted to top of reflector hold trim inside housing.

Trim retention (TOR): Two side-mounted torsion springs on the trim and two receiving brackets in the can, ensure a consistently tight fit with the ceiling.

Suitable for ceilings up to 1-1/2" thick.

  • Suggested Replacement Products

  • Spec Sheets

    Document Type Document Title Description Updated View
    {{document.DocumentType}} {{document.DocumentTitle}} {{document.Description}} {{document.UpdatedDate | date: 'MM/dd/yy'}} View
  • Photometry & Revit (BIM)

    Use %(percent) to separate search terms.<br >

    {{pager.startIndex + 1}} - {{pager.endIndex + 1}} of {{pager.totalItems | number:0}} results

    Description Report Design Tools
    {{photometryItem.Catalog}} Report
    • Request BIM or IES Files

      CLICK HERE to start your request for a BIM Model or IES file.
  • Specifications

    Size 6 IN
    Brand Lithonia Lighting
    CCT Not Applicable
    Environment Indoor
    Light Source Halogen, Incandescent, LED - Static
    Regulatory Listing cUL, IC, Non-IC
    Mounting Type Recessed
    Product Type Downlight
    Series L7XR
    Shape Round
    Voltage Rating 120
