LDN4 Round Series

LDN4 Round – 4” Open and Wallwash

By Lithonia Lighting

    Switchable LumensSwitchable CCTsEnergy Star®Buy America(n) Option AvailableLow UGR
  • Overview
  • Specifications
Read More
Read Less
Size 4 IN
Shape Round
Light Source LED - Static
Dynamic Feature Switchable White
Lumens 500 LM, 750 LM, 1000 LM, 1500 LM, 2000 LM, 2500 LM, 3000 LM, 4000 LM, Switchable
CCT / LED Color 2700 K, 3000 K, 3500 K, 4000 K, 5000 K, Variable
CRI 80, 90
Product Type Downlight
Compliance Listing BAA, Chicago Plenum, ENERGY STAR®, Low UGR
Environmental Listing ASTM Airtight, IC, Non-IC, Wet Location
Regulatory Listing cUL
Dimming Protocol 0-10V, DALI, Electronic Low Voltage, Triac
Fixture Wattage 10, 10.6, 11, 11.2, 11.3, 11.6, 12.8, 13.4, 13.5, 13.6, 14.2, 14.3, 14.5, 14.8, 14.9, 15.5, 15.8, 16.4, 17.5, 18, 18.8, 19, 20.2, 20.3, 20.5, 21, 21.8, 22.1, 24.1, 25, 25.1, 25.5, 25.6, 26.1, 27, 27.1, 28.6, 28.7, 29.1, 29.5, 31, 31.7, 32, 32.1, 33.1, 33.2, 34.7, 35.1, 35.4, 37.5, 37.6, 38.8, 39, 39.1, 40, 40.5, 40.6, 41.5, 43, 44, 46, 46.5, 47.5, 49, 5.74, 50, 51, 52, 53, 54, 55, 6.8, 8, 8.2, 8.3, 8.53, 8.6, 8.74, 9, 9.75, 9.8
Voltage Rating 120, 120-277, 277, 347
Trim Style Cone, Open, Single Wallwash
Color Black, Clear, White
Mounting Type Recessed
Series LDN4

Read More Read Less

  • Suggested Replacement Products


  • Spec Sheets

    Document Type Document Title Description Updated View
    Spec Sheet LDN4 SWW.pdf 4” Round Open and Wallwash Switchable LED Downlight 5/30/2024 View
    Spec Sheet LDN4.pdf 4" OPEN New Construction Downlight 5/30/2024 View

    Design Select
    Take Me There
    View Product
    View Now
  • Photometry & Revit (BIM)

    Use %(percent) to separate search terms.

    {{pager.startIndex + 1}} - {{pager.endIndex + 1}} of {{pager.totalItems | number:0}} results

    Description Report Design Tools
    {{photometryItem.Catalog}} Report
    CLICK HERE to start your request for a BIM Model or IES file.
  • Spectral Data Sheets

    >> CLICK HERE to Download Spectral Data FAQs

    Document Type Document Title Description Updated View
    Spectral Data Sheet SpectralDataSheet_LithoniaLighting_LDN4_30K_80CRI.pdf LDN4 35K 80CRI 6/1/2022 View
  • Technical Documents (e.g. Instruction Sheets, MSDS, CAD)

    Document Type Document Title Description Updated View
    Dimming Compatibility LBR-LDN-LDN Switchable Dimming Compatibility Dimming Compatibility Cheat Sheet 8/20/2020 View
    Installation Instructions 912-00205-001_LDN4-6 SWW Installation Instructions.pdf LDN4, LDN4SQ, LDN6 and LDN6SQ Round and Square Switchable New Construction LED Downlight 11/3/2020 View
    Installation Instructions 912-00219-001_LDN SWW CP Installation Instructions.pdf LDN4, LDN6 and LDN8 Round Switchable LED Downlight Supplemental for Chicago Plenum "CP" 12/10/2020 View
    Installation Instructions LDN 4 and 6 Installation Instructions.pdf LDN4, LDN4SQ, LDN6 and LDN6SQ Round and Square New Construction LED Downlight 1/5/2022 View
    Installation Instructions Sloped Ceiling Adapter CJ520663.pdf LDN4, LDN6 and LDN8 Round Sloped Ceiling Adapter "SCA" 10/20/2021 View
  • Utility Rebate Search

    To look-up a rebate for this product, please follow the steps below:

    Step 1Enter the Zip Code or Select the State and Utility

    Step 2Ensure that the correct Product Category is selected if there is more than one option
  • Replacement Parts

  • Confidential Documents

  • Marketing Material (e.g. Brochures, Sell Sheets, FAQs)

    Document Type Document Title Description Updated View
    Brochures Commercial Downlighting Product Brochure LBR and LDN Commercial Downlighting Product Portfolio Brochure 10/10/2023 View
    Brochures Commercial Downlighting School Application Guide LBR and LDN in Williams High School Application Guide 10/10/2023 View
    Brochures LDN Family Brochure LDN Downlights, Switchable, Retrofits, & Cylinders 10/10/2023 View
    Sell Sheet Commercial Downlight Comparison Chart LBR and LDN Product Families Comparison Chart 10/10/2023 View
    Sell Sheet LDN Ceiling Height Flyer.pdf LDN Ceiling Height Flyer 8/3/2017 View
    Sell Sheet LDN Switchable Sell Sheet LDN SWW1 (Sell Sheet) 9/21/2021 View
