RTAH

Round Tapered Aluminum Hinged Pole

by Lithonia Lighting

Round tapered aluminum hinged pole with standard 10-foot to 20-foot maximum mounting heights but can be provided in shorter lengths as needed. Excellent for applications where maintenance access is limited, e.g. Water Treatment Plants

Construction

Shaft: The shaft is spun tapered from seamless 6063 alloy aluminum tubing and heat treated to a T6 temper. Round in cross-section down length of shaft and cone tapered to the butt diameter.

Hinged anchor base: Cast from A356 aluminum alloy and heat treated to T6 temper. Shaft and tilting section of the hinged base are circumferentially welded top and bottom. The tilting and anchored sections of the hinged base are joined by a 3/4" diameter solid aluminum pivot rod. The tilting section of the hinged base is held in a vertical position by three 1/2"-13 x 2" stainless steel hex head bolts that attach to stainless steel inserts cast into the aluminum base. Hinge is considered side A of the pole for orientation purposes and signifies the downward direction the pole will lower.

Anchor bolts: Fabricated from carbon steel bar with minimum-yield strength of 55,000 psi. Bolts have an "L" bend on lower end and are galvanized a minimum of 12 inches on the threaded end per ASTM A-153. Each anchor bolt is furnished with two hex nuts and two flat washers.

Grounding: Anchor base plate is tapped for 3/8"-16 UNC stainless steel grounding bolt (provided by others).

Hand hole: Available as an option; Standard location is 90° to the right (side B) of the hinge (side A) and 18” above hinged base.

Hardware – All structural and non-structural fasteners are stainless-steel.

Finish: Must specify finish.

Additional options available. Refer to RTAH specification sheet for availability.

Check out POLESCENTRAL for additional resources and solutions.

Refer to this link for Light Pole Replacement Parts

  • Suggested Replacement Products

  • Spec Sheets

    Document Type Document Title Description Updated View
    {{document.DocumentType}} {{document.DocumentTitle}} {{document.Description}} {{document.UpdatedDate | date: 'MM/dd/yy'}} View
  • Photometry & Revit (BIM)

    Use %(percent) to separate search terms.<br >

    {{pager.startIndex + 1}} - {{pager.endIndex + 1}} of {{pager.totalItems | number:0}} results

    Description Report Design Tools
    {{photometryItem.Catalog}} Report
    • Request BIM or IES Files

      CLICK HERE to start your request for a BIM Model or IES file.
  • Specifications

    Brand Lithonia Lighting
    Color Almond, Beige, Black, Blue, Bronze, Brown, Gray, Green, Red, Silver, White, Yellow
    Environment Outdoor
    Finish Brushed, Gloss, Not Applicable, Textured
    Mounting Type Pole Mount
    Product Type Pole
    Series RTAH
