Recessed housing rated IC or Non-IC for 2x8 remodel applications. Approved for direct burial in insulation.
Air-tight aluminum housing with three remodel clips for installation in existing plaster, sheet rock or mechanical ceilings. Heavy-gauge galvanized steel raceway arm. Galvanized steel junction box with four built-in ROMEX® clamps and five 1/2" knockouts with slots for pryout. Not suitable for pulling wires.Rated for 90°C. Ground wire provided. Removable J-box door for easy access.
Trim retention (clips): Retaining clips riveted to top of reflector hold trim inside housing.
Trim retention (TOR): Two side-mounted torsion springs on the trim and two receiving brackets in the can, ensure a consistently tight fit with the ceiling.
Suitable for ceilings up to 1-1/2" thick.
Electronic 120V ballast with end of life protection. Class P thermally protected ballast protects against improper contact with insulation.
Socket base: 13W four-pin DTT (G24Q-1), TRT (GX24Q-1); 18W four-pin DTT (G24Q-2), TRT (GX24Q-2); 26W four-pin TRT (GX24Q-3).
Suggested Replacement Products
Need Product Assistance? (e.g. How to Buy, Technical Support, Warranty)
How to Buy
Acuity Brands lighting and controls products are primarily sold through a network of agents and distributors across North America,
as well as at more than 100 showroom or international locations and several online retailers.
Acuity Brands is dedicated to providing outstanding technical support. Please click on the appropriate link below, or feel free to
call us at 1.800.705.SERV (7378).
|CCT||3000 K, 3500 K|
|Light Source||Compact Fluorescent|
|Regulatory Listing||CSA Damp Location, cUL, IC, Non-IC, UL Damp Location|
|Lumen Output||Not Applicable|
|Series||L7XFR13D, L7XFR13T, L7XFR18D, L7XFR18T, L7XFR26T, L7XFR|
